Testing Facilities
The plant has a best in the class testing bench with power analyzer facility for accurate testing of the transformers.
- High frequency generator (DVDF-IOVT) 40 kVA, 900 V, 100 & 150 Hz
- Auto Voltage Regulator 3-Φ 300A, 0-470V
- High Voltage Transformer 100 kV, 500mA/1mA.
- High Voltage Transformer 5kV, 50mA
- Capacitor Switching Panel (226 KVAR, 1.1 KV with Panel)
- Semi Automatic operated Test bench with V/A/W meters,
- Ratio Meters with USB (TR-200)
- Power analyzers (VPA-60080)
- Loading Transformer (OC Test) : 100 kVA, 0.433/11kV
- Intermediate Transformer (SC Test) 300 kVA, 0.433/1.1-2.2-3.3 kV
- Break Down Voltage of Oil Testing Kit (100KV).
- Manually operated Test Bench with volt meter, Amp meter, watt meter setup for OC/SC, DVDF & HV Tests.
- CT/PT’s Details C.T Ratio.1: 5-10-25-50/5A
C.T Ratio.2: 100-150-200--300/5A
11 KV C.T Ratio.: 5-10-25-50/5A
3.6 KV C.T Ratio.: 100-150-200--300/5A
P.T Ratio: 3000-2000-1000-500V/500 V
P.T Ratio : 11KV/110V.
